Ducati Multistrada 1000 DS

Source: mediahouse.ducati.com

Technical data

Start of production	2004	End of production	2006
Cylinder	2	Valves	2
Cooling	air	Strokes	4
Displacement [ccm]	992	Bore [mm]	94
Stroke [mm]	71	Compression ratio	10:1
Max. Power [kW/hp]	62/84	RPM max. power [min-1]	8000
Max. torque [Nm]	84	RPM max. torque [min-1]	5000
Fuelt treatment	Marelli electronic fuel injection, 45 mm throttle body	EURO-norm	2
Gears	6	Ratio gears	1: 37/15, 2: 30/17, 3: 27/20, 4: 24/22, 5: 23/24, 6: 24/28
Front sprocket	15	Rear sprocket	42
Clutch	dry clutch	Wheelbase [mm]	1462
Rake [°]	24	Steering lock [°] left/right	35
Front suspension	Showa 43 mm USD-fork, fully adjustable	Front wheel travel [mm]	165
Front wheel	6-spokes light alloy 3.50 x17	Front tyre	120/70 ZR17
Rear suspension	Showa with aluminum swingarm	Rear wheel travel [mm]	141
Rear wheel	5-spokes light alloy 5.50 x 17	Rear tyre	180/55 ZR17
Front brake	320 mm dual disc, 4-piston-caliper	Rear brake	245 mm disc, 2-piston caliper
Weight [kg]	200	Seat height [mm]	850
Length [mm]	2130

Start of production	2004
End of production	2006
Cylinder	2
Valves	2
Cooling	air
Strokes	4
Displacement [ccm]	992
Bore [mm]	94
Stroke [mm]	71
Compression ratio	10:1
Max. Power [kW/hp]	62/84
RPM max. power [min-1]	8000
Max. torque [Nm]	84
RPM max. torque [min-1]	5000
Fuelt treatment	Marelli electronic fuel injection, 45 mm throttle body
EURO-norm	2
Gears	6
Ratio gears	1: 37/15, 2: 30/17, 3: 27/20, 4: 24/22, 5: 23/24, 6: 24/28
Front sprocket	15
Rear sprocket	42
Clutch	dry clutch
Wheelbase [mm]	1462
Rake [°]	24
Steering lock [°] left/right	35
Front suspension	Showa 43 mm USD-fork, fully adjustable
Front wheel travel [mm]	165
Front wheel	6-spokes light alloy 3.50 x17
Front tyre	120/70 ZR17
Rear suspension	Showa with aluminum swingarm
Rear wheel travel [mm]	141
Rear wheel	5-spokes light alloy 5.50 x 17
Rear tyre	180/55 ZR17
Front brake	320 mm dual disc, 4-piston-caliper
Rear brake	245 mm disc, 2-piston caliper
Weight [kg]	200
Seat height [mm]	850
Length [mm]	2130
