Technical data

Start of production	2003	Cylinder	2
Valves	2	Cooling	air
Strokes	4	Displacement [ccm]	992
Bore [mm]	94	Stroke [mm]	71
Compression ratio	10:1	Max. Power [kW/hp]	62/84
RPM max. power [min-1]	8000	Max. torque [Nm]	84
RPM max. torque [min-1]	6000	Fuelt treatment	Marelli electronic fuel injection, 45 mm throttle body
EURO-norm	2	Gears	6
Ratio gears	1: 32/13, 2: 30/18, 3: 28/21, 4: 26/23, 5: 22/22, 6: 24/26	Front sprocket	15
Rear sprocket	39	Clutch	dry clutch
Wheelbase [mm]	1440	Rake [°]	24
Steering lock [°] left/right	27	Front suspension	43 mm USD-fork
Front wheel travel [mm]	130	Front wheel	3-spokes light alloy 3.50 x 17
Front tyre	120/60 ZR17	Rear suspension	Sachs
Rear wheel travel [mm]	148	Rear wheel	3-spokes light alloy 5.50 x17
Rear tyre	180/55 ZR17	Front brake	320 mm dual disc, 4-piston-caliper
Rear brake	245 mm disc, 2-piston caliper	Weight [kg]	189
Seat height [mm]	800	Length [mm]	2105
Colours	red, black, yellow,

Start of production	2003
Cylinder	2
Valves	2
Cooling	air
Strokes	4
Displacement [ccm]	992
Bore [mm]	94
Stroke [mm]	71
Compression ratio	10:1
Max. Power [kW/hp]	62/84
RPM max. power [min-1]	8000
Max. torque [Nm]	84
RPM max. torque [min-1]	6000
Fuelt treatment	Marelli electronic fuel injection, 45 mm throttle body
EURO-norm	2
Gears	6
Ratio gears	1: 32/13, 2: 30/18, 3: 28/21, 4: 26/23, 5: 22/22, 6: 24/26
Front sprocket	15
Rear sprocket	39
Clutch	dry clutch
Wheelbase [mm]	1440
Rake [°]	24
Steering lock [°] left/right	27
Front suspension	43 mm USD-fork
Front wheel travel [mm]	130
Front wheel	3-spokes light alloy 3.50 x 17
Front tyre	120/60 ZR17
Rear suspension	Sachs
Rear wheel travel [mm]	148
Rear wheel	3-spokes light alloy 5.50 x17
Rear tyre	180/55 ZR17
Front brake	320 mm dual disc, 4-piston-caliper
Rear brake	245 mm disc, 2-piston caliper
Weight [kg]	189
Seat height [mm]	800
Length [mm]	2105
Colours	red, black, yellow,
