Ducati 999S
Source: mediahouse.ducati.com Technical data
| Start of production | 2003 | End of production | 2006 |
|---|---|---|---|
| Cylinder | 2 | Valves | 4 |
| Cooling | Liquid | Strokes | 4 |
| Displacement [ccm] | 998 | Bore [mm] | 100 |
| Stroke [mm] | 63 | Compression ratio | 11.4:1 |
| Max. Power [kW/hp] | 100/136 | RPM max. power [min-1] | 9750 |
| Max. torque [Nm] | 106 | RPM max. torque [min-1] | 800 |
| Fuelt treatment | Marelli electronic fuel injection, 54 mm throttle body | EURO-norm | 2 |
| Gears | 6 | Ratio gears | 1: 37/15, 2: 30/17, 3: 28/20, 4: 26/22, 5: 24/23, 6: 23/24 |
| Front sprocket | 15 | Rear sprocket | 36 |
| Clutch | dry clutch | Wheelbase [mm] | 1420 |
| Rake [°] | 23,5-24,5 | Steering lock [°] left/right | 28 |
| Front suspension | Öhlins USD with TiN coating, fully adjustable | Front wheel travel [mm] | 120 |
| Front wheel | 5-spokes Y light alloy 3.50 x 17 | Front tyre | 120/70 ZR17 |
| Rear suspension | Öhlins | Rear wheel travel [mm] | 128 |
| Rear wheel | 5-spokes Y light alloy 5.50 x 17 | Rear tyre | 190/50 ZR17 |
| Front brake | 320 mm dual disc, 4-piston-caliper | Rear brake | 240 mm disc, 2-piston caliper |
| Weight [kg] | 199 | Seat height [mm] | 780 |
| Length [mm] | 2095 | Colours | red, yellow |
| Colours wheels | grey-metallic |
| Start of production | 2003 |
|---|---|
| End of production | 2006 |
| Cylinder | 2 |
| Valves | 4 |
| Cooling | Liquid |
| Strokes | 4 |
| Displacement [ccm] | 998 |
| Bore [mm] | 100 |
| Stroke [mm] | 63 |
| Compression ratio | 11.4:1 |
| Max. Power [kW/hp] | 100/136 |
| RPM max. power [min-1] | 9750 |
| Max. torque [Nm] | 106 |
| RPM max. torque [min-1] | 800 |
| Fuelt treatment | Marelli electronic fuel injection, 54 mm throttle body |
| EURO-norm | 2 |
| Gears | 6 |
| Ratio gears | 1: 37/15, 2: 30/17, 3: 28/20, 4: 26/22, 5: 24/23, 6: 23/24 |
| Front sprocket | 15 |
| Rear sprocket | 36 |
| Clutch | dry clutch |
| Wheelbase [mm] | 1420 |
| Rake [°] | 23,5-24,5 |
| Steering lock [°] left/right | 28 |
| Front suspension | Öhlins USD with TiN coating, fully adjustable |
| Front wheel travel [mm] | 120 |
| Front wheel | 5-spokes Y light alloy 3.50 x 17 |
| Front tyre | 120/70 ZR17 |
| Rear suspension | Öhlins |
| Rear wheel travel [mm] | 128 |
| Rear wheel | 5-spokes Y light alloy 5.50 x 17 |
| Rear tyre | 190/50 ZR17 |
| Front brake | 320 mm dual disc, 4-piston-caliper |
| Rear brake | 240 mm disc, 2-piston caliper |
| Weight [kg] | 199 |
| Seat height [mm] | 780 |
| Length [mm] | 2095 |
| Colours | red, yellow |
| Colours wheels | grey-metallic |
