Technical data
| Start of production | 1971 |
End of production | 1974 |
| Cylinder | V2 90° |
Valves | 2 |
| Cooling | air |
Strokes | 4 |
| Displacement [ccm] | 748 |
Bore [mm] | 80 |
| Stroke [mm] | 74 |
Compression ratio | 8.5:1 |
| Max. Power [kW/hp] | 44/60 |
RPM max. power [min-1] | 7800 |
| Fuelt treatment | 30mm Amal R 930/76 and /77 |
Gears | 5 |
| Wheelbase [mm] | 1530 |
Front suspension | 38 mm Marzocchi-fork |
| Front wheel travel [mm] | 120 |
Front wheel | Borrani WM2x19 |
| Front tyre | 3,25 x 19 |
Rear suspension | Marzocchi swingarm with twin shock absorber |
| Rear wheel travel [mm] | 65 |
Rear wheel | Borrani WM3x18 |
| Rear tyre | 3,50 x 18 |
Front brake | 275 mm disc |
| Rear brake | 200 mm drum |
Weight [kg] | 185 |
| Max. speed [km/h] | 200 |
Colours | blue, Orange, Grün, red |
