Technical data

Start of production	1958	Cylinder	1
Cooling	air	Strokes	4
Displacement [ccm]	175	Bore [mm]	62
Stroke [mm]	57	Compression ratio	7:1
Max. Power [kW/hp]	8/11	RPM max. power [min-1]	6000
Fuelt treatment	UB22.5 BS 2	Gears	4
Wheelbase [mm]	1320	Front suspension	Marzocchi 32 mm fork
Front wheel	18 x 2	Front tyre	2,50 x 18 CEAT
Rear suspension	Marzocchi swingarm with twin shock absorber	Rear wheel	18 x 2,25
Rear tyre	2,75 x 18 CEAT	Front brake	158 mm drum
Rear brake	136 mm drum	Weight [kg]	104
Max. speed [km/h]	110	Colours	dark-red with white or blacken Highlights

Start of production	1958
Cylinder	1
Cooling	air
Strokes	4
Displacement [ccm]	175
Bore [mm]	62
Stroke [mm]	57
Compression ratio	7:1
Max. Power [kW/hp]	8/11
RPM max. power [min-1]	6000
Fuelt treatment	UB22.5 BS 2
Gears	4
Wheelbase [mm]	1320
Front suspension	Marzocchi 32 mm fork
Front wheel	18 x 2
Front tyre	2,50 x 18 CEAT
Rear suspension	Marzocchi swingarm with twin shock absorber
Rear wheel	18 x 2,25
Rear tyre	2,75 x 18 CEAT
Front brake	158 mm drum
Rear brake	136 mm drum
Weight [kg]	104
Max. speed [km/h]	110
Colours	dark-red with white or blacken Highlights
