Technical data
| Start of production | 1949 |
End of production | 1950 |
| Cylinder | 1 |
Cooling | air |
| Strokes | 4 |
Displacement [ccm] | 60 |
| Bore [mm] | 42 |
Stroke [mm] | 43 |
| Compression ratio | 8:1 |
Max. Power [kW/hp] | 1/1 |
| RPM max. power [min-1] | 5000 |
Fuelt treatment | Weber 15 MFC |
| Gears | 3 |
Front suspension | telescopic fork |
| Weight [kg] | 44 |
Colours | dark-red with goldenen Pinstripes |
| Start of production | 1949 |
|---|
| End of production | 1950 |
|---|
| Cylinder | 1 |
|---|
| Cooling | air |
|---|
| Strokes | 4 |
|---|
| Displacement [ccm] | 60 |
|---|
| Bore [mm] | 42 |
|---|
| Stroke [mm] | 43 |
|---|
| Compression ratio | 8:1 |
|---|
| Max. Power [kW/hp] | 1/1 |
|---|
| RPM max. power [min-1] | 5000 |
|---|
| Fuelt treatment | Weber 15 MFC |
|---|
| Gears | 3 |
|---|
| Front suspension | telescopic fork |
|---|
| Weight [kg] | 44 |
|---|
| Colours | dark-red with goldenen Pinstripes |
|---|
