Ducati Multistrada 1200 S Granturismo

Responsive image Source: Ducati-Press

Technical data

Start of production2013 End of production2015
Cylinder2 Valves4
Coolingliquid Strokes4
Displacement [ccm]1198 Bore [mm]106
Stroke [mm]67 Compression ratio11.5:1
Max. Power [kW/hp]110/150 RPM max. power [min-1]9250
Max. torque [Nm]118 RPM max. torque [min-1]7500
Fuelt treatmentMitsubishi electronic fuel injection, elliptical throttle body EURO-norm3
Gears6 Ratio gears1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=22/25
Front sprocket15 Rear sprocket40
ClutchWet clutch, hydraulic control Wheelbase [mm]1530
Rake [°]25 Steering lock [°] left/right38
Front suspensionSachs 48 mm USD-fork, fully adjustable, eletronic adjustable Front wheel travel [mm]170
Front wheel10-spokes light alloy, 3.50 x 17 Front tyre120/70 ZR17 Pirelli Angel GT
Rear suspensionSachs, voll elektronische einstellbar, aluminum single-sided swingarm Rear wheel travel [mm]170
Rear wheel10-spokes light alloy, 6.00 x 17 Rear tyre190/55 ZR17 Pirelli Angel GT
Front brake320 mm dual disc, 4-piston-2-pad-radial-caliper with ABS Rear brake245 mm disc, 2-piston caliper
Weight [kg]217 Seat height [mm]850
Length [mm]2200 Coloursred with white stripe
Colours wheelsblack InstrumentsLCD + Dot Matrix
Electric FeaturesDSS, DTC, Hands-Free, Drivemodes
Start of production2013
End of production2015
Cylinder2
Valves4
Coolingliquid
Strokes4
Displacement [ccm]1198
Bore [mm]106
Stroke [mm]67
Compression ratio11.5:1
Max. Power [kW/hp]110/150
RPM max. power [min-1]9250
Max. torque [Nm]118
RPM max. torque [min-1]7500
Fuelt treatmentMitsubishi electronic fuel injection, elliptical throttle body
EURO-norm3
Gears6
Ratio gears1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=22/25
Front sprocket15
Rear sprocket40
ClutchWet clutch, hydraulic control
Wheelbase [mm]1530
Rake [°]25
Steering lock [°] left/right38
Front suspensionSachs 48 mm USD-fork, fully adjustable, eletronic adjustable
Front wheel travel [mm]170
Front wheel10-spokes light alloy, 3.50 x 17
Front tyre120/70 ZR17 Pirelli Angel GT
Rear suspensionSachs, voll elektronische einstellbar, aluminum single-sided swingarm
Rear wheel travel [mm]170
Rear wheel10-spokes light alloy, 6.00 x 17
Rear tyre190/55 ZR17 Pirelli Angel GT
Front brake320 mm dual disc, 4-piston-2-pad-radial-caliper with ABS
Rear brake245 mm disc, 2-piston caliper
Weight [kg]217
Seat height [mm]850
Length [mm]2200
Coloursred with white stripe
Colours wheelsblack
InstrumentsLCD + Dot Matrix
Electric FeaturesDSS, DTC, Hands-Free, Drivemodes
